IPC Hand Soldering Competition - Manila Philippines October 10 to 12 , 2019

IPC Hand Soldering Competition held last October 10 to 12 , 2019 at the SMX Convention Center, Mall of Asia, Pasay City , Philippines



November 19, 2019 -IMI PHILS BAGS THIRD PLACE AT THE 2019 IPC HAND SOLDERING WORLD CHAMPIONSHIP

IMI PHILS BAGS THIRD PLACE AT THE 2019 IPC HAND SOLDERING WORLD CHAMPIONSHIPEmail Print Facebook Twitter

November 19, 2019, Laguna, Philippines — Integrated Micro-Electronics, Inc., (IMI) one of the leading global technology solutions experts, announced that IMI’s Philippines’ Maricel Calabig Velasco placed 3rd out of the 17 contestants from several countries who competed at the IPC Hand Soldering Competition World Championship last November 14 in Munich, Germany.

The contestants were challenged to complete a functional assembly within 60 minutes fully compliant with the IPC-A Class 3 criteria for solderability, the highest standard among the IPC classes. Finalists were then assessed by the panel of judges in terms of speed and functionality. Velasco got 315/340 points within a time frame of 57 minutes and 59 seconds, garnering third place. Representatives from Indonesia and France won first and second place, respectively.

Hand soldering is a process used to repair, modify or connect different points in a printed circuit board (PCB) assembly. Since the reliability of an electronic equipment is guaranteed by zero-defect soldering processes, the world championship paid tribute to the best skills in hand soldering complex PCB assemblies.

Representatives from Germany, France, United Kingdom, Hungary, Poland, China, Malaysia, Indonesia, Japan, Korea, India, Thailand, Vietnam and the Philippines were among those who competed and showcased their soldering skills.

Now known as the Association Connecting Electronics Industries, the Institute of Printed Circuits (IPC) is a trade association that aims to standardize the assembly and production requirements of electronic equipment and assemblies.

source =  https://www.global-imi.com/news/imi-phils-bags-third-place-2019-ipc-hand-soldering-world-championship#

October 15, 2019 - IMI PHILS BAGS GRAND PRIZE AT THE IPC HAND SOLDERING COMPETITION

IMI PHILS BAGS GRAND PRIZE AT THE IPC HAND SOLDERING COMPETITION

Email Print Facebook Twitter

October 15, 2019. Laguna Philippines.  A production operator from IMI Philippines, Maricel Velasco and technician Cristina Bautista, won the first and second prize respectively at the recently concluded IPC Hand Soldering Competition held last October 10 to 12 at the SMX Convention Center, Pasay City.

The reliability of an electronic equipment is ensured by zero-defect soldering processes. The contest recognizes the best skills in hand soldering complex printed board assemblies.

Both Velasco and Bautista bested 38 contestants from twelve notable technology and electronics companies who participated in the competition.

Velasco will represent the country to compete at the 2019 IPC International Hand Soldering World Championship that will be held at Munich, Germany from November 12 to 15 this year.

The event was held for the first time in the Philippines. IPC has been organizing this competition in several Southeast Asian countries for the past seven years to encourage companies to utilize the IPC standards to improve the quality of printed circuits.

“Many of the contestants have the skills but only few can solder the components with the appropriate and necessary speed,” asserts Johnson Muriel, master IPC trainer and one of the judges during the competition.  The participants were expected to mount all the components in 50 minutes and the units must be functional and should pass the IPC-A-610G Class 3 criteria for solderability.

Class 3 is the highest standard of the IPC classes. Passing the criteria signifies that an electronic assembly was built in accordance with all of the IPC criteria for electronic materials and solderability in the medical and automotive markets.

IPC was founded in 1957 as the Institute of Printed Circuits and is now known as the Association Connecting Electronics Industries. It is a trade association that aims to standardize the assembly and production requirements of electronic equipment and assemblies.

About IMI

Integrated Micro-Electronics Inc. (IMI), the manufacturing portfolio of AC Industrials, Inc., a wholly-owned subsidiary of Ayala Corporation is among the leading global technology solutions company in the world.  IMI ranks 17th in the list of top 50 EMS providers in the world by the Manufacturing Market Insider, based on 2018 revenues. In the automotive market, it is the 5th largest EMS provider in the world per New Venture Research.

IMI specializes in highly reliable and quality electronics for long product life cycle segments such as automotive, industrial electronics and the aerospace market.

From its manufacturing plants in the Philippines, China, Bulgaria, Czech Republic, Germany, Japan, Mexico, Serbia, United Kingdom and the United States, IMI provides engineering, manufacturing, and support and fulfillment capabilities to diverse industries globally.

Source=  https://www.global-imi.com/news/imi-phils-bags-grand-prize-ipc-hand-soldering-competition#

MOBILE PHONE LCD SEPARATOR Uyue 948Z

Uyue 948Z
Lagunastar SKU= UYUE-948Z

SPECIFICATIONS:

Voltage: 110V/220V

Size: 320*180*128 mm

Weight: 3kg

Output Power: 300W

110/220V Separator Machine Built-in Pump Vacuum Metal Body Vacuum For 8 inch  Glass/Touch Screen/LCD Separator Uyue 948z

Application:
Step 1: Put rubber mat on heating plate.
Step 2: Turn vacuum button (s1/ s2) on, put LCD screen on rubber mat and fix tightly.

Step 3: Turn on the machine and wait for the metal plate become 80-100 degree C.

Step 4: Start to separate the LCD off the glass with cutting wire, then right and left movement with wire between the LCD and the glass, please notice that you must using gentle power and keep wire stay on the LCD surface, so that it will avoid the damage of touch screen.

Step 5: Finally you have finished the separating work, and do a good job.

Attention:

1. Do not produce the heat more than 110 degree C when operating, or high temperature may destroy the LCD Screen.

2. We have 220V and 110V item on sale, please tell us what kind of item do you need, or we will send the item out according to your own country's voltage.

Advantages:

1. More convenient.  This Latest Upgraded Vacuum LCD Separator with Vacuum Pump Built-in, get rid not only of the traditional fixture clamps or screws, but of the heavy Vacuum Pump.
You do not worry whether the LCD is fixed well any more when you work.
2. Larger heating plate.  It can be used for mobile phone Max 8 inch universal, without the clamps on the panel, working plate gets larger.
3. Lower noise & lighter weight . The previous vacuum pump now has changed into a mini vacuum generator, with lighter weight, and the generator inside works quietly.

Features:

1. Enough heating metal plate : for mobile Max 8 inch universal;
2. Built-in Vacuum Pump, low noise, no need fixture clamps or outside heavy connect any more;
3. Safety power system inside, avoiding the electric leakage problem;
4. Anti static body material, prevent the LCD and the flex cable being damaged from the static;
5. Easy to operate, manual separating;
6. Smooth metal plate to hold the touch screen without any damaged;
7. Power supply: AC 85V to AC 265V 50Hz , almost for users from all over the world;
8. Temperature should be set to 80 centigrade to 100 centigrade, when you do the job on iPhone and galaxy series ect;
9. Compatible for LCD or LED screen assembly;
10. With Safety power system to avoid leakage.

MOBILE PHONE LCD SCREEN SEPARATOR UYUE 948Q

UYUE 948Q

Lagunastar SKU= UYUE-948Q

DESCRIPTION:

This machine helps people to separate OCA glue between LCD and screen glass, using this machine, you can separate the broken glass from LCD and if LCD is still working well, you just need to replace a Glass screen.

No need to use full expensive assembly screen to replace them, as that is too expensive.

Heating plate is made of integrative alloy-aluminum with good and well distributed heat conduction, and won’t easy out of shape although under-high temperature.

With 4 adjustable fixed tools to hold your replacement parts on the machine firmly.

With LED display, you can get the clearly Temperature information on it

Application Range: Separation the different cover plate, LCD and so on.

WORKING ENVIRONMENT:

Working Voltage: AC~220V-250V

Working Temperature: 0-55degrees

====

notes:

1.     When you use the screen separator, please put it on the working table, make sure the table is even flat and the material of the table is heat-resistant.

2.     The heating plate is very hot when the screen separator is working, please pay attention to it.

3.     Please pay attention to the item you’d like to separate; the item will be damaged if the temperature is too high.

4.     Stop using the screen separator besides the flammable and combustible things.

5.     You can move or touch the screen separator when you have powered screen separator off and its cool down.

6.     Please power the screen separator off when you needn’t use it.

===

Notes:

1. Model Number: UYUE 948Q

Color: Black

Voltage: 110V/220V

Usage: LCD screen separator Max screen repair: 7 inch

Power: 400W

Material: Sheet metal

Heating area: 100*200mm

948Q Built-in Vacuum Pump LCD Separator Machine /Seperator to

Repair /Split /Separate Glass Touch Screen Digitizer for iPhone,Samsung

Features:

1.Built-in vacuum pump
2.Material: sheet metal
3.UY-100 more precise temperature controller;

4.Smooth heating plate surface
5.LCD screens can be firmly fixed on the panel
6.For any 2.5~7 inches LCD screens
7.Heating Area(mm):100*200
8.Power:400W;
9.Voltage:AC100 ~240V;

How to use it:

1. Just put on LCD on the heating panel, turn on "Vacuum Pump" switch, then you can separate the glass. And the LCD is firmly fixed on the panel while separating.
2. The LCD Screen Separator is used for separating glass lens, touch screen and LCD display assembly for Apple, Samsung, HTC as well as other cell phones.

Like the current main stream cell phones, Apple, Samsung and HTC, many new cell phones are made of display assembly. Since glass lens, touch screen and LCD are connected together, it is hard to separate cracked or broken screen by hand if happened. Always you have to take it to Depot for repairing. The cost is high and the time is long. Or you need purchase expensive equipment package, including separate machines, SMT machines, laminating machine and bubble removing machine.
But now you can handle it easily. We have developed the machine and skills, it is unnecessary to buy expensive equipments and wide space for general repair shops. After mastering the skills, you can replace an old screen within 3 minutes and it looks like a new one

Packing

1x LCD Touch Screen Separator 220V or 110V
1 x Cutting Line 50m
1 x Pair of Rods
1 x Silicone pad

13 packs contain:

Hexagon Plum Screwdriver: T3, T4, T5, T6
Spiral screwdriver: 0.8
Phillips screwdriver: 1.5,2.0
Flat screwdriver: 2.0
Cross pry bar * 1, round pry bar * 1, sucker * 1, triangular piece * 1, disassemble sheet * 1

2. other photos:
