AFR-2000 Pneumatic Filter Regulator Air Treatment Unit Pressure Switches Gauge AFR2000

 Air Filter & Pressure Gauge AFR-2000



 SKU= AFR-2000





AFR-2000 Pneumatic Filter Regulator Air Treatment Unit Pressure Switches Gauge AFR2000



 Features:

AFR2000 air filter regulator is that adjust The main channel of air pressure to a pressure value what the control device required after filtration through decompression.
No matter the size of the inlet pressure and flow fluctuations, always maintain a stable outlet pressure
Light weight, small size, easy installation and maintenance
Can filter small particles, keep the air clean
If the output pressure is higher than the set pressure, the discharge pressure of the atmosphere to maintain a stable output
Application:air compressors, pneumatic tools and other gas connection installation, effectively filter the air moisture.
Specifications:

Model: AFR2000 (AFR is the model, 2000 refers to the port size)
Material: body (aluminum die-casting products), Yung cup (polycarbonate)
Fluid: Air
Port size: G1 / 4
Filtration precision: 5μm
Operating pressure range: 0 ~ 1.0MPa (manual drain: 0-9.5kgf / cm2, differential pressure discharge: 1.5-9.5kgf / cm2)
Temperature: 5 ~ 60 °
Gauge caliber: G1 / 8
Treatment cup capacity: 15CM3
Length: appox 15cm
Installation and Use :
The direction shown by the arrow on the valve body is installed, which is the direction of the gas flow direction.

Package Included:

1pcs Filter regulator
