HANSTAR ZCUT-9 Automatic Tape Dispenser for Kapton Tape/Teflon tape/Paper tape







Automatic Tape Dispenser
HANSTAR ZCUT-9
The most popular type of Japanese automatic tape dispenser with ability to store up to 6 different lengths in the memory.

Model ZCUT-9 is a fully programmable tape dispenser equipped with a precise photoelectric cut-off blade controlled by two individual photocells. Tape dispenser ZCUT-9 does not require any tape's core support or shaft and enables to easily process two tapes simultaneously.
FEATURES:
  • any size of tapes fit without bobbins
  • cut length from 5mm to 999mm
  • safety function and design, antistatic body
  • memory function enables to set six different length before use
  • enable to cut protection film, copper foil, aluminum foil, insulation material and many more
  • enable to hold the film or tape by using flexible tape support
  • preset and loop counter functions, all displayed by LED counter
  • enable to use 2 rolls at the same time
  • smart design, build-in tweezers, oil and separator
SPECIFICATIONS:
Cut length
5 - 999 mm
Tape width
6 - 60 mm
Usable tape
filament, strong, acetate cloth, glass cloth, double-sided, normex, pre-stick, cellophane, craft, masking, plastic and more
Usable film
protection, paper, insulation, aluminum, copper etc.
Feeding speed
200 mm/sec (when cutting packing tape)
Max outside diameter
300 mm
Accessories
power cord, 2A fuse (built-in inlet), separator, guide plate, tweezers, blade oil
Body material
anti-static ABS
Display/counter
3 digit LED display
Power supply
AC240V 50/60Hz 25W
Dimensions
116 mm(W) x 140 mm(H) x 213 mm(D)
Weight
2.5kg


=====
notes:
1. mas malakas ang cutting power nito as compared to the M-1000. if hirap ang M-1000 sa tape na kinacut. ito ang suggested model

2. ZCut-9 is fit for any tape:Vinyl tape, ene polyethylene tape, acetate acid base cloth tape, ordinary paper, aluminum foil tape, bilateral tape, polyester film tape, teflon tape, masking tape,glass cloth tape, cloth tape, etc.
